Description
Overview
Freudenberg dry operating gas diffusion layers for fuel cell applications include H24C5 and H23C3. This product group is designed for LT-PEM fuel cell development under dry and very dry operating conditions, offering higher thickness and extended dry diffusion length compared with thinner GDL grades. Both materials are suitable for fuel cell stack development, application-oriented material selection, prototyping and performance evaluation where dry operating behavior is a key design consideration.
Key Features
- Freudenberg dry operating gas diffusion layer family for fuel cell applications
- Available grades: H24C5 and H23C3
- Designed for dry and very dry LT-PEM fuel cell operating conditions
- Higher thickness and extended dry diffusion length for specialized stack requirements
- Low electrical resistance and engineered permeability profiles
- Suitable for fuel cell development, evaluation and stack optimization
Technical Specifications
| Property | H24C5 | H23C3 | Unit |
|---|---|---|---|
| Hydrophobic Treatment | No | Yes | — |
| Microporous Layer | Yes | Yes | — |
| Thickness @ 0.025 MPa | 270 | 290 | µm |
| Thickness @ 1 MPa | 215 | 230 | µm |
| Area Weight | 130 | 150 | g/m² |
| Compression Set @ 1 MPa | 15 | 25 | µm |
| TP Electrical Resistance @ 1 MPa | 9 | 9 | mΩ·cm² |
| IP Electrical Resistance | 0.7 | 0.6 | Ω |
| TP Air Permeability acc. to Gurley | 40 | 35 | s |
| IP Air Permeability @ 1 MPa | 2.5 | 1.5 | µm² |
| Tensile Strength | > 70 | > 70 | N/50mm |
| Dry Diffusion Length | 1000 | 1400 | µm |
Note: TP = through-plane; IP = in-plane. Technical data shown above are average values subject to usual production tolerances and do not represent formal product specifications.
Applications
- LT-PEM fuel cells
- Dry operating fuel cell systems
- Very dry operating fuel cell applications
- Fuel cell stack design and GDL material selection
- Research, prototyping and performance evaluation
Commercial Note
Prices shown on this page are indicative reference prices and may vary depending on quantity, packaging format and market conditions. Listed prices exclude VAT, shipping and any custom cutting or packaging services. Bulk orders, customized dimensions and distributor cooperation are available upon request. Please contact us for detailed quotations and technical support.
